Introducing the C&H Direct Mount Optic for CZ optics ready pistols. No adapter plate required. The CZ-DMO is a rugged, compact pistol optic that is as good for concealed carry as it is for duty, home defense, or fun at the range. Available in red and green multi-reticle versions. Compatible with P10 and Shadow 2.
FEATURES
10 levels of brightness (level 1 and 2 are night vision compatible)
Motion control (shake awake)
Smart power management (auto-off after 5 mis of inactivity)
50,000 hours battery life
CNC machined one-piece body (7075 aircraft grade aluminum)
Shock rated for +P and +P+
Waterproof (ipx7, 1 meter for 30 mins)
SPECIFICATIONS
Magnification: | 1x |
Lens Diameter: | 21mm |
Elevation/Windage adjustment range: | 35 MOA (Total 70 MOA) |
Click Value: | 1 MOA per click |
Dot Size: | 3 MOA DOT 27 MOA circle multi-reticle |
Dot Color: | Red or Green versions |
Parallax Free: | 33 Yards |
Red Dot Brightness Setting: | 10 levels |
Power Supply: | 1x CR 1632 3V Lithium battery |
Auto Wake/Sleep: | 225 seconds after no movement |
Shockproof & Waterproof | |
Dimensions: | (LxWxH) 2.05in x 1.06in x 1.04in |
Weight (with battery installed): | 1.2oz (approx.) |
Footprint: | CZ Optics Ready |
Click Here to download the manual
b_cavanagh (verified owner) –
I would honestly consider this a below average sight. Average would be 3 stars. Hence, the 2 stars. Firstly, the dot is fairly poor in its clarity and containment. It’s not crisp and exhibits a lot of blooming and stray light diagonally. The glass is much smaller than most any other optic on the market. The sealant between the glass and the frame is very poorly done with large variations in thickness and some spots missing sealant or signs it’s worn away (despite being shot only twice). The irons in the rear are completely useless. I was attracted to this over the direct mount from holosun because this had built in irons but they could never be used for anything as they are far too low and wouldn’t allow for any meaningful targeting. The emitter appears to be completely unprotected. The screws included are domed despite countersunk holes. It just makes no sense. You have these screws sticking up that look like you swapped them out with what you found at home depot but no they’re factory. I would say it barely gets the job done but it’s certainly no point of pride on a CZ Shadow 2 Orange OR with various aftermarket parts making a gun that costs $3k+.
heparker (verified owner) –
AMAZING! Direct mount was super easy to mount and zero was almost perfect out of the box. Sits low and flush to the slide. Housing is beefy and glass is clear. Brightness and controls are excellent. Tools included, battery included, QR code for instructions and manual. This DMO is a winner!
