EDC-XL

$274.95 – $299.95

The EDC-XL is a rugged, compact pistol optic that is as good for concealed carry as it is for duty, home defense, or fun at the range. Available in red, and multi-reticle versions. The EDC-XL mounts onto any RMR footprint slide or plate.

FEATURES
10 levels of brightness (level 1 and 2 are night vision compatible)
Motion control (shake to wake up)
Smart power management (auto-off after 5 mis of inactivity)
50,000 hours battery life
CNC machined one-piece body (7075 aircraft grade aluminum)
Shock rated for +P and +P+
Waterproof (ipx7, 1 meter for 30 mins)

(2 customer reviews)



Receive 25% off on any Adapter Plate or 25% off any Slide Milling Service when you add one to your cart with this optic. The discount will be reflected in the cart.

The EDC-XL is a rugged, compact pistol optic that is as good for concealed carry as it is for duty, home defense, or fun at the range. Available in red, and multi-reticle versions. The EDC-XL mounts onto any RMR footprint slide or plate.
FEATURES
10 levels of brightness (level 1 and 2 are night vision compatible)
Motion control (shake awake)
Smart power management (auto-off after 5 mis of inactivity)
50,000 hours battery life
CNC machined one-piece body (7075 aircraft grade aluminum)
Shock rated for +P and +P+
Waterproof (ipx7, 1 meter for 30 mins)
SPECIFICATIONS

Magnification: 1x
Lens Diameter: 22mm
Elevation/Windage adjustment range: 45 MOA (Total 90 MOA)
Click Value: 1 MOA per click
Dot Size: 3 MOA DOT (27 MOA circle also in multi-reticle version)
Dot Color: Red
Parallax Free: 33 Yards
Red Dot Brightness Setting: 10 levels
Power Supply: 1x CR 1632 3V Lithium battery
Auto Wake/Sleep: 225 seconds after no movement
Shockproof & Waterproof
Dimensions: (LxWxH) 1.78in x 1.18in x 1.08in
Weight (with battery installed): 0.8oz (approx.)
Footprint: RMR

Click Here to download the manual



IRON SIGHTS DISCLAIMER:
When making aftermarket firearm modifications, factory components can often become obsolete, particularly when mounting optics on the slide, whether through direct milling or using a plate. Achieving the correct height for low co-witness iron sights depends on factors such as the firearm type, mounting plate, optic, and slide cut. For assistance in determining the appropriate iron sight height for your specific setup, please contact our Customer Service team through our dedicated contact portal.

Additional information

Weight 0.8 lbs
Dimensions 1.78 × 1.18 × 1.08 in
Select Your Model

EDC XL – Red, EDC XL – Red MR

2 reviews for EDC-XL

  1. Julius Milton (verified owner) –

    Nice, clear dot with easy to use buttons…however…

    I can’t call this an effective tool. The battery tray screw flew out while shooting. C&H sent me more screws, which I added blue loctite (never had to do this with Holosun optics) and although the screw it still in there, the battery compartment doesn’t seem to be tight because my dot does not come on unless I tap the door. I do not feel safe with this product. Giving it two stars because when it works it’s nice.

  2. Chris Reulbach (verified owner) –

    I’ve been and RMR guy for years and recently picked up an EDC-XL for my Glock 19 after seeing Scott Jedlinkski smack one of these around and toss it 30 feet in the air. So far the sight is excellent! Great window size, clear glass, great initial build quality. If it stands up to the abuse I’m sure to give it, CHPWS has a total winner.

    My only complaint is I would like an auto brightness feature for CCW. Other than that it’s perfect. And the price is fantastic.
